Cerebellum／granule cell layer

See the anatomy of the Cerebellum

Hematoxylin-eosin stain

Info？

NO
YES

The granule cells looks like lymphocytes. There are cerebellar glomeruli (circles) which contain the axon terminals of the mossy fibers, the dendritic terminals of the granular cells and the axon terminals of the Golgi cells.

Kluver-Barrera stain

Info？

NO
YES

The granule cells looks like lymphocytes. There are cerebellar glomeruli (circles) which contain the axon terminals of the mossy fibers, the dendritic terminals of the granular cells and the axon terminals of the Golgi cells.

Bodian stain

Info？

NO
YES

The granule cells looks like lymphocytes. There are cerebellar glomeruli (circles) which contain the axon terminals of the mossy fibers, the dendritic terminals of the granular cells and the axon terminals of the Golgi cells.
