Cerebral cortex / primary visual cortex

See the anatomy of the cerebral cortex

Hematoxylin-eosin stain

Info？

NO
YES

The middle layer of the primary visual cortex (Brodmann’s area 17) has abundant myelin sheaths, although HE stain could not show so.

Kluver-Barrera stain

Info？

NO
YES

The middle layer of the primary visual cortex (Brodmann’s area 17) has abundant myelin sheaths, which forms a blue line (macroscopically called “stria of Gennari).
