Basal ganglia / striatum (putamen)

See the anatomy of the basal ganglia

Hematoxylin-eosin stain (low power)

Info？

NO
YES

Bundles of the nigrostriatal tract (arrows) are noticed.

Kluver-Barrera stain (low power)

Info？

NO
YES

Bundles of the nigrostriatal tract (arrows) are noticed.

Hematoxylin-eosin stain

Info？

NO
YES

There are both large neurons (a yellow arrow) and small neurons (blue arrows) in the putamen.

Kluver-Barrera stain

Info？

NO
YES

There are both large neurons (a yellow arrow) and small neurons (red arrows) in the putamen.
